Fluke
Networks NTS2 NetTool Series II
|
|
Troubleshooting network
connectivity problems can be a daunting and time-consuming
task. Without the right tool, network techs can spend hours
of unnecessary time with trial and error guesswork trying to
isolate the problem.
Fluke Networks has put an end to the guessing game with the
NetTool Series II Inline Network Tester. NetTool combines
powerful NetProve diagnostics, inline Gigabit vision, VoIP
Phone PC configuration testing in one palm-sized tool, so
you'll have everything you need to quickly resolve even the
toughest connectivity problem. Plus, with the monitoring and
authentication option, you'll have the power to identify
port-based security threats and maintain user connectivity
in 802.1x environments.
The right tool for the job
Since no two networks are identical, Fluke Networks offers
several NetTool models and options to match your individual
requirements and to maximize the value of your NetTool
investment. From our top-of-the-line NetTool Series II
Network Service Kit to the entry-level NetTool 10/100, you
will find a NetTool model that fits your network
troubleshooting needs and your budget.
|
|
|
|
NetProve™ diagnostics –
isolate device and application connectivity issues in seconds
|
|
|
Inline Gigabit vision - quickly
troubleshoot network problems with powerful inline vision into
10/100/Gig traffic between switches, PCs, IP phones and other
devices
|
|
|
Monitoring and authentication
- identify spyware, malware, and viruses with port monitoring;
troubleshoot authentication issues with 802.1x log
|
|
|
VoIP troubleshooting - connect
inline for visibility into VoIP calls to quickly diagnose IP phone
boot-up and call control problems and to measure key call quality
metrics |
|
|
PoE Measurements - verify
readiness of PoE systems and troubleshoot PoE device problems
|
|
|
Spot available
network resources – See MAC and IP addresses, subnet and
services offered by active servers, routers and printers
|
|
|
IntelliTone digital signaling
- quickly and safely locate cables on active network |
|
|
|
NetTool Series II
General Specs NTS2 |
|
|
Media Access 10/100/1000 Base -TX and PoE (802.3af)
|
|
|
Cable Tests Internal wiremap. WireView Cable ID,
cable length, opens, shorts, and split pairs
|
|
|
Cable Toner IntelliTone or Analog (each with two
songs)
|
|
|
Cable Length Accuracy is +/- (10% or reading plus 1
meter) |
|
|
Ports Shielded Hub/NIC connector (RJ-45) and USB
input jack
|
|
|
Interface Push button navigation of icon/menu-drivan
view
|
|
|
Battery Removable alkaline batteries or optional
rechargeable NIMH AA batteries
|
|
|
Dimensions 19.0 cm x 8.9 cm x 4.4 cm (7.5" x 3.5" x
1.75")
|
|
|
Weight 0.54 kg (1 lb 3 oz.)
|
|
|
Warranty One year (extended warranty available) |
|
|
LED Indicators (8) 10/100/1000 (Link), CLSN/ERR
(Collision/error), UTIL (Utilization), PoE, and CHARGE
|
|
|
|
NetTool Series II Inline Network
Tester Features |
|
|
Network security threats and measures to combat them have an
increasingly large impact on your ability to maintain frontline
connectivity. The monitoring and authentication option allows you to
identify port-based security threats and troubleshoot connectivity
problems in 802.1X secured environments. |
|
|
Traffic from malware, spyware, and viruses can degrade user PC
performance, not to mention threaten the integrity of the network.
The Port Monitor feature allows you to configure your NetTool Series
II to differentiate between expected and unexpected port traffic,
which is key to detecting these malicious applications. Easily add
and remove expected ports using the NetConnect Software. NetTool
will automatically recognize and flag unexpected traffic during
troubleshooting. |
|
|
Load a list of expected ports from the NetConnect Software. |
|
|
View IP address, port number, protocol, frame type, number of
frames, and traffic size of expected or unexpected ports. |
|
|
802.1X is quickly becoming the preferred authentication protocol for
protecting networks against unauthorized users and rogue devices.
Monitoring and authentication can help in pre-deployment
verification of 802.1X, and in post-deployment troubleshooting.
During deployment, your enterprise 802.1X settings can be loaded
onto a NetTool. The NetTool then emulates a client on the network
and establishes a connection using the loaded credentials. |
|
|
Emulate a device and link to the network to verify 802.1X
configuration settings. |
|
|
During troubleshooting, the 802.1X Log can be used to monitor the
authentication process inline between a PC and the network. All
communication will be displayed on the screen and areas of failure
will be identified. With the monitoring and authentication feature,
you can uncover the root cause of user authentication issues fast
without fussing around with time consuming trial and error. |
|
|
View communication inline during the authentication process. |
|
|
Identify reasons for failure during the authentication process. |
|
|
|
| Fluke Networks
NTS2-NSKIT Network Service Kit: |
$3695.00 |
[Add to Cart] |
|
NTS2-NSKIT NetTool Series II Network Service Kit includes
10/100/1000Mbps inline, VoIP option, monitoring and authentication option,
NetProve diagnostics, IntelliTone toning, IntelliTone Pro 200 Probe, NetTool
Connect PC software, WireView Wiremappers #1-6, set of 4 AA alkaline
batteries, NiMH battery/charger kit, USB to mini-USB cable, Ethernet cable,
Getting Started Guide, CD with Multilanguage User Manuals, TPAK meter
hanging kit, and deluxe carrying case. |
|
| Fluke Networks
NTS2-VOIP NetTool Series II Pro VoIP |
$3095.00 |
[Add to Cart] |
|
NTS2-VOIP NetTool Series II Pro VoIP includes 10/100/1000Mbps inline,
VoIP option, NetProve diagnostics, IntelliTone toning, NetTool Connect PC
software, WireView Wiremapper #1, set of 4 AA alkaline batteries, USB to
mini-USB cable, Ethernet cable, Getting Started Guide, CD with Multilanguage
User Manuals, and soft carrying case |
|
| Fluke Networks
NTS2-PRO NetTool Series II Pro
|
$2595.00 |
[Add to Cart] |
|
NTS2-PRO NetTool Series II Pro includes 10/100/1000Mbps inline, NetProve
diagnostics, IntelliTone toning, NetTool Connect PC software, WireView
Wiremapper #1, set of 4 AA alkaline batteries, USB to mini-USB cable,
Ethernet cable, Getting Started Guide, CD with Multilanguage User Manuals,
and soft carrying case |
|
|
Options and Accessories |
| Fluke Networks
NTS2-VOIP-OPT Upgrade from NTS2-PRO to NTS2-VOIP |
$649.00 |
[Add to Cart] |
| Fluke Networks
NT-VOIP-OPT Upgrade from NT-PRO to NT-VOIP |
$650.00 |
[Add to Cart] |
| Fluke Networks
NT-PRO-OPT Upgrade from NT to NT-PRO |
$1195.00 |
[Add to Cart] |
| Fluke Networks
NTS2-POWERPAK AC adapter and NiMH battery set for Series II |
$ |
[Add to Cart] |
| Fluke Networks DTX-ACUN
AC universal adapter for Series II |
$57.00 |
[Add to Cart] |
| Fluke Networks BATT-AA-NIMH
(4) Rechargable NiMH battery set (4) for all models |
$18.55 |
[Add to Cart] |
| Fluke Networks NT-AC-ADAP
AC adapter for 10/100 |
$26.65 |
[Add to Cart] |
| Fluke Networks NT-BATT-CHG
NiMH battery charger for 10/100 |
$65.00 |
[Add to Cart] |
| Fluke Networks WIREVIEW
2-6 WireView WireMappers #2-6 for Series II |
$315.00 |
[Add to Cart] |
| Fluke Networks
NT-HOLSTER Holster for 10/100 |
$28.00 |
[Add to Cart] |
| Fluke Networks GLD-NT
Gold priority support for all models (1 year) |
$268.00 |
[Add to Cart] |
