Fluke DTX
1800 Category 6
CableAnalyzers are Three times faster than existing testers with
9-second Cat 6 Autotest.
Fluke DTX 1800 CableAnalyzer Series
|
Click for larger image
|
It all starts with 9-second Cat 6 Auto test that means you can meet TIA-568-B
certification requirements and receive structured cabling warranties much
faster than ever before. With all this speed also comes increased accuracy.
The DTX is the only independently verified TIA Accuracy Level IV tester to
obtain UL accuracy classification. And, you'll be prepared for emerging new
cabling technologies such as 10Gig Ethernet thanks to DTX's 900MHz frequency
range. With the DTX Series, you're ready for whatever the world throws at
you - today and tomorrow. DTX CableAnalyzer Overview
- Exceeds spec requirements for Cat 5e/6 and Class E/D/F
- Independently verified by UL to meet ISO Level IV and proposed TIA
Level IIIe Accuracy requirements
- Three times faster than existing testers with
9-second Cat 6 Auto test
- Advanced time-saving diagnostics pinpoints fault and suggests
corrective actions
- 900 MHz future-proofs your investment for future applications such
as 10 Gigabit Ethernet, Class F and CATV
- Resident fiber modules lets you switch between copper and fiber with
the push of a button
- DTX significantly reduces total certification costs by as much as
33% a year
10GB Upgrade Kit
Fluke DTX Brochure
Fluke DTX
CableAnalyzer USERS MANUAL
Fluke DTX Model Comparison Chart |
| Advanced Diagnostics |
| When a link fails, the DTX Series provides
quick and easy-to understand directions to identify the point of failure
(distance from the tester) and the possible reason(s) for the failure.
These directions not only tell you the problem, but also identify
corrective actions your test technicians can take to solve the problem
quickly — all without having to consult with the project manager. Instead of
spending time executing trial and error corrections — and re-testing to find
out whether the problem has been resolved — the technician knows exactly
where to look and what to do to fix the failing link.
|
Level IV Accuracy |
| Until now, testers have been designed to meet
accuracy Level III. The more demanding accuracy Level IV specification has
been proposed in ISO/IEC (international standards) to test Class F links to
600 MHz. DTX testers exceed this new specification, assuring you of higher
confidence in results over the full frequency range.
|
Test Standards
- TIA Category 3 and 5e per TIA/EIA-568B
- TIA Category 5 (1000BASE-T) per TIA TSB-95
- TIA Category 6 per TIA/EIA-568B.2-1 (Addendum #1 to TIA/EIA-568B.2)
- ISO/IEC 11801 Class C, D, and E
- ISO/IEC 11801 Class F (DTX-1800 only)
- EN 50173 Class C, D, E
- EN 50173 Class F (DTX-1800 only)
- ANSI TP-PMD
- IEEE 802.3 10BASE-T, 100BASE-TX, 1000BASE-T
- IEEE 802.5 (STP cabling, IBM Type 1, 150Ω ) Token Ring, 4 Mbps and
16 Mbps
|
|
Fluke DTX-1800 Fluke Networks CableAnalyzer 900MHZ |
$7,645.00 |
[Add to Cart] |
|
Fluke DTX-1800M Fluke Networks CableAnalyzer 900MHZ with Multimode
Probes |
$10,669.00 |
[Add to Cart] |
|
Fluke DTX-1800MS Fluke Networks CableAnalyzer 900MHZ with Multimode
and Singlemode Probes |
$15,699.00 |
[Add to Cart] |
| DTX-1800 CableAnalyzer: Includes
DTX-1800 Main and Smart Remote, LinkWare PC Software,
128MB MMC Card, Cat 6/Class E Permanent Link Adapters
(2), Cat 6/Class E Channel Adapters (2), Headsets for
Talk (2), AC Chargers (2), Carrying Case, USB Interface
Cable (Mini-B), Serial RS-232 Cable (DB9 to IEEE1394),
User Manual |
| |
|
Fluke DTX Options and Accessories |
|
DTX-CHA001S Cat 6/Class E Channel Adapters, set of 2 |
$255.00 |
[Add to Cart] |
|
DTX-PLA001S Universal Permanent Link Adapters (2) with PM06
Personality Module |
$715.00 |
[Add to Cart] |
|
DTX-PCU6S DTX Series UTP Cat 6 Patch
Cord Adapter Set Includes:
DTX Main adapter (DTX-PCU6/MN) and DTX Smart Remote adapter (DTX-PCU6/SR) |
$665.00 |
[Add to Cart] |
|
DTX-COAX DTX Coax Cable Test Adapter (2 adapters included) |
$565.00 |
[Add to Cart] |
|
DTX-SER Serial RS-232 Cable (DB-9 to IEEE1394) |
$30.00 |
[Add to Cart] |
|
DSP-PM06
Cat 6 Centered Personality Module
PM06 is the first centered, shielded plug test Cat 6 compliance and
interoperability. This global test solution suports all UTP, FTP and ScTP
cabling systems (Cat 3,5,5e and 6). Approved by
major connectivity manufacturers.
(Pair) |
$205.00 |
[Add to Cart] |
|
DTX-LION Lithium Ion Battery Pack |
$280.00 |
[Add to Cart] |
|
DSP-PM10B Cat 6 (IDC) Permanent Link Personality Modules
for testing
110-Style IDC Systems
Avaya 110 T568B |
$165.00 |
[Add to Cart] |
|
DSP-PM13B Cat 6 (IDC) Permanent Link Personality Modules
for testing
110-Style IDC Systems
Siemon S210 T568B |
$165.00 |
[Add to Cart] |
|
GLD-DTX GOLD SUPPORT SERVICES 1-YR FOR DTX |
$715.00 |
[Add to Cart] |
|
| |
|
|
